BỘ PHÁT WIFI NGOÀI TRỜI GRANDSTREAM GWN7605LR

Model

GWN7605LR

Wi-Fi Standards

IEEE 802.11a/b/g/n/ac (Wave-2)

Antennas

2 dual band external antennas
2.4GHz, gain 3.5dBi
5 GHz, gain 3.5dBi

Wi-Fi Data Rates

IEEE 802.11ac: 6.5 Mbps to 867 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5Mbps to 300Mbps
IEEE 802.11b: 1, 2, 5.5, 11Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Frequency Bands

2.4GHz Radio: 2412-2484 MHz
5 GHz Radio: 5180-5825 MHz

Channel Bandwidth

2.4G: 20 and 40MHz
5G: 20, 40 and 80 MHz

System Security

WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device

MIMO

2×2:2 2.4GHz (MIMO)
2×2:2 5GHz (MU-MIMO))

Coverage Range

Up to 250 meters

Maximum TX Power

2.4G: 24 dBm
5G: 22dBm

Receiver Sensitivity

- 2.4G
   + 802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
- 5G: 802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40: -63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9

SSIDs

8 SSID per radio

Concurrent Clients

100+

Network Interfaces

2× autosensing 10/100/1000 Base-T Ethernet Ports

Auxiliary Ports

1× Reset Pinhole

Mounting

Outdoor metal bar mount or wall mount, kits included

LEDs

1× tri-color LEDs for device tracking and status indication

Network Protocols

IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM

QoS

802.11e/WMM, VLAN, TOS

Network Management

Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs
GWN Manager (BETA) offers premise-based software controller for up to 3,000 GWN Aps

Power and Green Energy Efficiency

PoE 802.3af/ 802.3at;
Maximum Power Consumption: 10.16W

Environmental

Operation: -30°C to 70°C
Storage: -30°C to 80°C
Humidity: 5% to 95% Non-condensing

Physical

Unit Dimension: 358.3mm(L)x115mm(W)x45.3mm(H); Unit Weight: 500g
Entire Package Dimension: 258 × 247× 86mm; Entire Package Weight:655.3g

Weatherproof Grade

IP66-level weatherproof capability when installed vertically

Compliance

FCC, CE, RCM, IC
